Model | LBS-024A |
Size | 29.5*13.1mm |
Work system | GSM850/900/1800/1900；CDMA800/1900；WCDMA B1/2/4/5/8/19 |
Frequency range | 2.4-2.5GHz；5.15-5.85GHz |
Impedance | 50Ω |
V.S.W.R | ≦3 |
Peak Gain | ＞1 dBi |
TRP: | 2.4G >11dBm 5G>11dBm |
TIS: | ≦-65dBm |
The connection method | welding/connector |
Polarization | Linear polarization |
Working temperature | -40℃~+85℃ |
Long-term storage temperature | +19℃~+23℃ |
Note | working frequency band, size, connection mode and RF line can be customized |
LBS-024A is a WiFi dual-band antenna used in ECG monitor, and it is a small terminal antenna with high anti-interference.
The horizontal direction of the antenna (H-plane) is omnidirectional, with high gain and high efficiency. The VSWR of the two frequency bands is lower than 2, which meets the requirements of the wireless characteristic parameters of the antenna in the monitoring room.
The antenna feed point and form are optimized to make the antenna unit gain high efficiency, wide frequency band and low SAR value. In the active state test, THE TRP/TIS of IEEE 802.11a/ B/G/N should meet the network access standard to ensure the communication stability of the ECG monitor.
